TIGRA — MCF-T1 Caster Frame
PN: 40.336.200.01
 | The MCF‑T1 Caster Frame provides safe transport for up to four (4) TIGRA loudspeakers and is integral to array assembly and disassembly. Caster‑alignment guides enable easier stacking of empty caster frames. The casters are rated to support the maximum array weight on two wheels during array assembly and disassembly. |
PRODUCT | |
Part number | 40.336.200.01 |
Product compatibility | TIGRA-L, TIGRA-W |
MATERIALS AND FINISH | |
Primary materials | Steel |
Finish | Low-gloss powder coating |
Exterior color | Black |
Custom color available | No |
RIGGING AND SAFETY | |
Safety restrictions | Do not transport more than four (4) TIGRA on an MCF-T1. |
Rigging load capacity | Capable of supporting the maximum array weight on two casters. |
WEIGHTS AND MEASURES | |
Product weight | 75 lb (34 kg) |
Shipping weight | |
Weight - caster frame + 4 loudspeakers | 555 lb (252 kg) |
Outer dimensions | W: 24.80 in (884 mm) x H: 12.52 in (318 mm ) x D: 24 in 610 mm (610 mm) |
CARE AND MAINTENANCE | |
Painting | If bare metal becomes exposed, touch up with spray paint to prevent rust. |
Cleaning | Wipe with a damp cloth. |
PN: 04.330.000.00 A 2604 |
